Another Glide question 2400 lb tube car

Old 01-05-2010, 02:08 PM
  #1
haddixj
Junior Member
SHOW GUEST
Thread Starter

Join Date: Jan 2010
Posts: 1
Default Another Glide question 2400 lb tube car

First things first, I have a 70 Duster that I am putting together and will be using a BBC and I have a glide I want to use. I need to measure to see which I have, 1.76 or 1.8, but I want to switch to a turbo shaft because I have a converter for it and its better from what I hvae read on here. What is the best combination I have, the motor is a 454 nothing special but I want to build the trans the way I want it the first time. What is a stock case good to HP wise? anyother suggestions for the valve body brand? dont plan on using a transbrake, also need a good source for parts.
Thanks
Jason

[img][/img]
haddixj is offline
Old 01-05-2010, 03:11 PM
  #2
TheYellaBrick
Senior Member
RACING JUNKIE

TheYellaBrick's Avatar

Join Date: Mar 2008
Location: Emmett, Idaho
Posts: 7,334
Default

CHEVY in a MOPAR !! :shock: :shock: :shock: :shock: :shock: :shock:
Why that's BLASPHEMY !! and just plain WRONG........ :shock: :shock: :shock: :shock:
In all fairness, it looks like a fun project,especially the MOPAR BODY and COLOR
TheYellaBrick is offline
Old 01-05-2010, 04:21 PM
  #3
BEAST477
Senior Member
RACING JUNKIE

BEAST477's Avatar

Join Date: Feb 2007
Location: Michigan
Posts: 1,908
Default

Chevy in a Mopar? Sounds like a good idea to me. But what do I know? :shock: :wink:
BEAST477 is offline
Old 01-05-2010, 06:39 PM
  #4
kwkracing
Senior Member
RACING JUNKIE

Join Date: Dec 2004
Location: austin texas
Posts: 729
Default

If you are using a stock glide output shaft you want to use the 1.76. The case is good for alot of power if everything is properly set up. I have had many blown bbc all steel cars with 1.76 stock gear sets and cases. I have used valvebodys from just about all name brands with no problems i can remember. Hughes, tci, coan, tsi,jw performance,bte....
kwkracing is offline
Old 01-05-2010, 06:42 PM
  #5
zipper06
Senior Member
RACING JUNKIE

Join Date: Jan 2006
Location: La.
Posts: 2,890
Default

Ouch :!: :!: ,

Mopar Mark is gonna luv this application, good choice :idea:

But back to the PG, measure the input shaft, if it measures 12 5/8" long it's a 1.82 , if it measures 12 7/8" long it's a 1.76 planaterie. You need to have a 1.76, because a BBC with eat a 1.82 faster than a hog can eat an ear of corn.

JMO

Zip.
zipper06 is offline
Old 01-05-2010, 06:45 PM
  #6
MEMRACING62
Senior Member
RACING JUNKIE

Join Date: Sep 2007
Location: orland pk il
Posts: 2,429
Default

SOMETHING TELLS ME MARK AINT GONNA LIKE THIS!! :shock: :shock: :shock:
MEMRACING62 is offline
Old 01-05-2010, 06:55 PM
  #7
jmarksdragster
Senior Member
RACING JUNKIE

jmarksdragster's Avatar

Join Date: Jul 2007
Location: Florida
Posts: 635
Default

THe factory case will work fine. A stock 1.76 will be good if you run in the 9's or slower, 9.0's and faster I would invest in an aftermarket gearset. Remember that good factory gearsets are hard to come by, and not a bad investment to run aftermarket gears if you can afford it at any level. For any PG parts, www.tsr-racing.com. Their valve body design is good, I would recommend a trans brake VB even if you don't plan on using it right away. You don't have to use it now, but will have it if you need in the future.
jmarksdragster is offline
Old 01-07-2010, 02:08 PM
  #8
rob41willys
Senior Member
SENIOR BUILDER

Join Date: Nov 2007
Location: Tukwila, WA
Posts: 115
Default

I agree that you should spend the extra money on an aftermarket planatary, i've seen them for under 700.00 for 1.80 straight cut. I also just ordered some stuff from TSR also, good to deal with. Stock case will be just fine as long as your not putting a bunch of power to it.
rob41willys is offline
Old 01-07-2010, 09:19 PM
  #9
russ67chevelle
Senior Member
EXPERT BUILDER

Join Date: Jan 2005
Posts: 336
Default

hey its a great idea with a bbc in anything!!! 8)

dont be afraid to put a th400 behind it,i run in the 8s with mine in a tube chassis car...funner to drive!!!
russ67chevelle is offline
Old 01-07-2010, 10:29 PM
  #10
cepx111
Senior Member
RACING JUNKIE

Join Date: May 2006
Posts: 2,044
Default

I would recommend a complete tranny.

For right at a grand you can have one shipped to your door ready to bolt in.
Far cheaper than building one from scratch IMO and a whole less headache ordering parts, cleaning & re-assembling.

BTE, TCI, T/S all have entry level powerglides that are rated for around 800 HP just shop around and compare.
I ended up with a abruzzi racing entry level powerglide, they list in the classifieds.
I'm very pleased with it.

Cp
cepx111 is offline
